2022 Porsche 911 GT3 PDK (992.1) Specs
Here are the technical specifications of the 2022 Porsche 911 GT3 with the PDK transmission. Specs of the EU model. Technical specs may vary depending on the country.
2022 Porsche 911 GT3 PDK Specs
Engine
- Type: Six-cylinder horizontally opposed naturally aspirated engine
- Cylinders: 6
- Valves/cylinders: 4
- Displacement: 3,996 cm3
- Bore: 102.0 mm
- Stroke: 81.5 mm
- Maximum power: 375 kW (510 PS) at 8,400 rpm
- Maximum torque: 470 Nm at 6,100 rpm
- Maximum power output per litre: 93.8 kW/I (127.6 PS/l)
- Compression ratio: 13.3:1
- Maximum engine speed: 9,000 rpm
- Cooling system: Water cooling with mechanical thermostat
- Valve control: VarioCam camshaft control for intake and exhaust valves, DLC-coated rocker arms, fixed valve train
- Intake system: Variable intake manifold made of plastic with two switchable resonance valves and six individual throttle valves
- Oil supply: Dry-sump lubrication with fully variable oil pressure pump, seven scavenge pumps, oil centrifuge and additional oil supply via crankshaft, fine oil separator
Transmission
- Drive system: Rear-wheel drive
- Gearbox: Seven-speed dual-clutch transmission (PDK), Porsche Torque Vectoring Plus (PTV+) incl. electronic rear differential lock with fully variable torque distribution
Chassis
- Suspension and damping: Adjustable sports suspension, Porsche Active Suspension Management (PASM) variable damping system with sports setup and ride height lowered by 20 mm
- Front axle: Double-wishbone front suspension with anti-roll bar, all chassis mounts ball joints, integrated helper spring
- Rear axle: Multi-link rear axle, anti-roll bar, chassis bearings partial with ball joints, integrated helper spring
- Steering: Electromechanical power steering with variable steering ratio and speed-dependent power steering, rear-axle steering with GT3 sport tuning
- Steering ratio: 14.2:1 (centre position) to 11.2:1
- Steering wheel diameter: 360 mm
- Turning circle diameter: 10.4 m
- Vehicle stability system: Porsche Stability Management (PSM) incl. ABS, can be switched off in two stages (ESC OFF and ESC+TC OFF)
Brakes
- Brake system: Dual circuit brake system with brake discs at the front and rear, vacuum brake booster, braking assist; electric duo-servo parking brake, auto-hold function; multi-collision brake
- Front axle brakes: Six-piston aluminium monobloc fixed calliper brakes, dimpled and internally vented grey cast iron composite brake discs with aluminium brake chambers
- Diameter: 408 mm
- Thickness: 34 mm
- Rear axle brakes: Four-piston aluminium monobloc fixed calliper brakes, dimpled and internally vented grey cast iron composite brake discs with aluminium brake chambers
- Diameter: 380 mm
- Thickness: 30 mm
Wheels and Tyres
- Front wheels: 9.5 J x 20 ET 46
- Front tyres: 255/35 ZR20
- Rear wheels: 12 J x 21 ET 45
- Rear tyres: 315/30 ZR21
Dimensions
- Length: 4,573 mm
- Width: 1,852 mm (2027 mm with exterior mirrors)
- Height: 1,279 mm
- Wheelbase: 2,457 mm
- Front track width: 1,601 mm
- Rear track width: 1,553 mm
- Luggage compartment volume: 132 l
- Kerb weight according to DIN: 1,435 kg
- Permissible gross weight: 1782 kg
- Weight-to-power ratio: 3.8 kg/kW
Performance
- Top speed: 318 km/h
- 0-60 mph: 3.2 s
- 0-100 km/h: 3.4 s
- 0-160 km/h: 7.0 s
- 0-200 km/h: 10.8 s
Fuel and Emissions
- Fuel type: Super Plus (98 RON)
- Fuel consumption urban: 17.3 l/100 km
- Fuel consumption extra-urban: 9.5 l/100km
- Fuel consumption combined: 12.4 l/100km
- CO2 emissions combined: 283 g/km
- Tank capacity: 64 l (optional 90 l)
- Drag coefficient (cd): 0.34
