Technical Data

2020 Porsche 718 Cayman T PDK (982) Specs

by James

Here are the technical specifications of the 2020 Porsche 718 Cayman T with a PDK transmission. This information refers to the EU model. The technical data may vary from country to country.

Engine

  • Type: Turbo flat engine with gasoline particulate filter (GPF)
  • Cylinders: 4
  • Valves/cylinders: 4
  • Displacement: 1,988 cm3
  • Bore: 91.0 mm
  • Stroke: 76.4 mm
  • Maximum power output: 220 kW (300 PS) at 6,500 rpm
  • Maximum torque: 380 Nm at 2,150-4,500 rpm
  • Maximum output per litre: 111 kW/l (151 PS/l)
  • Compression ratio: 9.5:1
  • Maximum engine speed: 7,500 rpm
  • Cooling system: Water cooling with thermal management and switchable water pump
  • Valve control: Camshaft adjustment and VarioCam Plus valve lift adjustment for intake and exhaust
  • Oil supply: Integrated dry sump lubrication and demand-controlled oil pump
  • Engine charging: Mono turbocharging
  • Intercooling: Indirect intercooling (two low-temperature air-water radiators and one water-intercooler)
  • Exhaust system: Dual-branch exhaust system with central stainless steel tailpipe

Transmission

  • Drive system: Mid-engine, rear-wheel drive
  • Transmission: Seven-speed Porsche dual clutch PDK transmission, Porsche Torque Vectoring (PTV) with mechanical rear differential lock

Chassis

  • Suspension and damping: PASM sports chassis, steel suspension and hydraulic gas-filled vibration dampers, Porsche Active Suspension Management (PASM)
  • Front axle: Lightweight spring-strut suspension (McPherson type, Porsche-optimized)
  • Rear axle: Lightweight spring-strut suspension (McPherson type, Porsche-optimized)
  • Steering: Electromechanical power steering with variable steering ratio and steering pulse input
  • Steering ratio: 15.0:1 (centre position) to 12.5:1
  • Steering wheel diameter: 360 mm
  • Turning circle diameter: 10.98 m
  • Vehicle stability system: Porsche Stability Management (PSM) incl. ABS with extended brake functions

Brakes

  • Brake system: Four-piston aluminium monobloc fixed-calliper brakes at the front and rear, electric parking brake
  • Front brake discs: Grey cast iron, internally vented and perforated
  • Diameter: 330 mm
  • Thickness: 28 mm
  • Rear brake discs: Grey cast iron, internally vented and perforated
  • Diameter: 299 mm
  • Thickness: 20 mm

Wheels and Tyres

  • Front wheels: 8 J x 20 ET 57
  • Front tyres: 235/35 ZR 20
  • Rear wheels: 10 J x 20 ET 45
  • Rear tyres: 265/35 ZR 20 tyres

Dimensions

  • Length: 4,379 mm
  • Width: 1,801 mm (1,994 mm with door mirrors)
  • Height 1,276 mm
  • Wheelbase 2,475 mm
  • Track width, front 1,528 mm
  • Track width, rear 1,534 mm
  • Luggage volumes and weights
  • Luggage volumes 425 l (front 150 l, rear 275 l)
  • Unladen weight (DIN) 1,380 kg
  • Allowable gross weight 1,685 kg

Performance

  • Top speed: 275 km/h
  • 0-60 mph: 4.7 seconds
  • 0-60 mph with Sport+: 4.5 seconds
  • 0-100 km/h: 4.9 seconds
  • 0-100 km/h with Sport+: 4.7 seconds
  • 0-160 km/h: 11.1 seconds
  • 0-160 km/h with Sport+: 10.8 seconds
  • 0-200 km/h: 18.1 seconds
  • 0-200 km/h with Sport+: 17.8 seconds

Fuel and Emissions

  • Fuel type: Super Plus (98 RON)
  • Fuel consumption urban: 10.8 l/100 km
  • Fuel consumption extra-urban: 6.5 l/100 km
  • Fuel consumption combined: 8.1 l/100 km
  • CO2 emissions combined: 185 g/km
  • Efficiency class in Germany: G
  • Fuel tank capacity: 54 l
  • Drag coefficient (cd): 0.30
