2019 Porsche 911 Carrera 4S PDK (992.1) Specs

Here are the technical specifications of the 2019 Porsche 911 Carrera 4S with the PDK transmission. This information refers to the EU model. The technical data may vary from country to country.

2019 Porsche 911 Carrera 4S PDK Specs

Engine

• Type: Six-cylinder boxer engine with twin-turbo charge, gasoline particulate filter (GPF)
• Cylinders: 6
• Valves/cylinders: 4
• Displacement: 2,981 cm³
• Bore: 91.0 mm
• Stroke: 76.4 mm
• Maximum power output: 331 kW (450 PS) at 6,500 rpm
• Maximum torque: 530 Nm at 2,300-5,000 rpm
• Maximum output per litre: 111 kW/l (151 PS/l)
• Compression ratio: 10.2:1
• Maximum engine speed: 7,500 rpm
• Cooling system: Water cooling with map-controlled thermal management and switchable water pump
• Valve control: VarioCam Plus, Camshaft adjustment for intake and outlet, valve lift adjustment for intake

Transmission

• Drive system: Porsche Traction Management (PTM), Active all-wheel drive with electronically controlled map-controlled multi-plate clutch, variable torque distribution between front and rear axle, Porsche Torque Vectoring Plus (PTV Plus) including electronic rear differential lock with fully variable torque distribution
• Transmission: Eight-speed dual-clutch transmission (PDK)

Chassis

• Suspension and damping: Steel suspension and hydraulic gas-filled vibration dampers, Porsche Active Suspension Management (PASM)
• Front axle: Spring-strut suspension, wheels independently suspended on wishbones with trailing links and struts (McPherson type, Porsche-optimized)
• Rear axle: Lightweight multi-link suspension with wheels independently guided on five suspension arms

Steering

• Steering: Electromechanical power steering with variable steering ratio and steering pulse, optional rear-axle steering (RAS)
• Steering ratio: 15.0:1 (centre position), with RAS 14.1:1
• Steering wheel diameter: 360 mm
• Turning circle diameter: 11.2 m
• Vehicle stability system: Porsche Stability Management (PSM) incl. ABS with extended brake functions

Brakes

• Front brakes: Six-piston aluminium monobloc fixed calliper brakes
• Brake discs: Grey cast iron, internally vented and perforated
• Diameter: 350 mm
• Thickness: 34 mm
• Rear brakes: Four-piston aluminium monobloc fixed calliper brakes
• Brake discs: Grey cast iron, internally vented and perforated
• Diameter: 350 mm
• Thickness: 28 mm
• Electric parking brake

Wheels and Tyres

• Front wheels: 8.5J x 20 ET 53
• Front tyres: 245/35 ZR 20 tyres
• Rear wheels: 11.5J x 21 ET 67
• Rear tyres: 305/30 ZR 21 tyres

Dimensions

• Length: 4,519 mm
• Width: 1,852 mm (2,024 mm with door mirrors)
• Height: 1,300 mm
• Wheelbase: 2,450 mm
• Front track width: 1,589 mm
• Rear track width: 1,557 mm
• Luggage volumes: 132 l
• Unladen weight (DIN): 1,565 kg
• Allowable gross weight: 2,010 kg
• Roof load (with Porsche roof transport system): 75 kg

Performance

• Top speed 306 km/h
• 0-60 mph: 3.4 seconds
• 0-60 mph with Sport Plus: 3.2 seconds
• 0-100 km/h: 3.6 seconds
• 0-100 km/h with Sport Plus: 3.4 seconds
• 0-160 km/h: 8.3 seconds
• 0-160 km/h with Sport Plus: 8.0 seconds
• 0-200 km/h: 12.7 seconds
• 0-200 km/h with Sport Plus: 12.4 seconds

Fuel and Emissions

• Fuel type: Super Plus (98 RON)
• Fuel consumption urban: 13.1 l/100 km
• Fuel consumption extra-urban: 7.8 l/100 km
• Fuel consumption combined: 9.7 l/100 km
• CO2 emissions Combined: 222 g/km
• Efficiency class in Germany: G
• Fuel tank capacity: 67 l
• Drag coefficient (cd): 0.29
