2018 Porsche 718 Cayman GTS PDK (982) Specs

Here are the technical specifications of the 2018 Porsche 718 Cayman GTS with the PDK transmission. Technical data may vary depending on country. This date refers to the EU model.

2018 Porsche 718 Cayman GTS PDK Specs

Engine

• Type: Turbocharged flat engine with gasoline particulate filter (GPF)
• Cylinders: 4
• Valves/cylinder: 4
• Displacement: 2,497 cm³
• Bore: 102.0 mm
• Stroke: 76.4 mm
• Maximum power output: 269 kW (365 PS) at 6,500 rpm
• Maximum torque: 430 Nm at 2,100-5,000 rpm
• Maximum output per litre: 107.7 kW/l (146.2 PS/l)
• Compression ratio: 9.5:1
• Maximum engine speed: 7,500 rpm
• Cooling system: Water cooling with thermal management and switchable water pump
• Valve control: Camshaft adjustment and VarioCam Plus valve stroke switching for intake and exhaust
• Oil supply: Integrated dry sump lubrication and demand-controlled oil pump
• Engine charging: Mono turbocharging with VTG charger (variable turbine geometry); maximum charge pressure 1.25 bar
• Intercooling: Indirect intercooling (two low-temperature air-water radiators and a water intercooler)
• Exhaust system: Dual-branch exhaust system with central stainless steel tailpipe

Power Transmission

• Drive system: Mid-engine, rear-wheel drive
• Transmission: Seven-speed Porsche dual clutch transmission; Porsche Torque Vectoring (PTV) with mechanical rear differential lock

Chassis

• Suspension and damping: Porsche Active Suspension Management (PASM) with electronically controlled dampers; steel suspension lowered by 10 mm
• Front axle: Lightweight spring-strut suspension (McPherson type, Porsche-optimized)
• Rear axle: Lightweight spring-strut suspension (McPherson type, Porsche-optimized)
• Steering: Electromechanical power steering with variable
• Steering ratio: 15.0:1 (centre position) to 12.5:1
• Steering wheel diameter: 360 mm
• Turning circle diameter: 10.98 m
• Vehicle stability system: Porsche Stability Management (PSM) incl. ABS with extended brake functions; separately selectable PSM Sport mode.

Brakes

• Brake system: Dual circuit brake system with brake discs at the front and rear; vacuum brake booster; braking assist; electric duo-servo parking brake; hold function; multi-collision brake
• Front brakes: Four-piston aluminium monobloc parking brake; internally vented and perforated cast iron
• Diameter: 330 mm
• Thickness: 34 mm
• Rear brakes: Four-piston aluminium monobloc parking brake; internally vented and perforated cast iron
• Diameter: 299 mm
• Thickness: 20 mm

Wheels and Tyres

• Front wheels: 8 J x 20 ET 57
• Front tyres: 235/35 ZR 20
• Rear wheels: 10 J x 20 ET 45
• Rear tyres: 265/35 ZR 20

Dimensions

• Length: 4,393 mm
• Width: 1,801 mm (with door mirrors 1,994 mm)
• Height: 1,286 mm
• Wheelbase: 2,475 mm
• Front track width: 1,527 mm
• Rear track width: 1,535 mm
• Luggage volume: 425 l (front 150 l, rear 275 l)
• Fuel tank capacity: 64 l
• Unladen weight (DIN): 1,405 kg
• Allowable gross weight: 1,705 kg
• Weight-to-power ratio: 3.85 kg/hp

Performance

• Top speed: 290 km/h (213 mph)
• 0-60 mph: 4.1 seconds
• 0-60 mph with Sport+: 3.9 seconds
• 0-100 km/h: 4.3 seconds
• 0-100 km/h with Sport+: 4.1 seconds
• 0-160 km/h: 9.3 seconds
• 0-160 km/h with Sport+: 9.0 seconds
• 0-200 km/h: 14.5 seconds
• 0-200 km/h with Sport+: 14.2 seconds

Fuel and Emissions

• Emissions standard: Euro 6d-Temp (EU6 AG)
• Fuel type: Super Plus (98 RON)
• Fuel consumption urban: 11.5 l/100 km
• Fuel consumption extra-urban: 6.7 l/100 km
• Fuel consumption combined: 8.5 l/100 km
• CO2 emissions combined: 194 g/km
• Efficiency class in Germany: F
• Drag coefficient (cd): 0.32
