2015 Porsche Cayman GTS (981) Specs

Here are the technical specifications of the 2015 Porsche Cayman GTS. The technical data may vary according to markets.

2015 Porsche Cayman GTS Technical Specifications

Body

• Type: Two seat Coupe; lightweight body in aluminium-steel construction with doors, boot and bonnet lids made of aluminium; two-stage driver and front passenger airbags; side and head airbags for driver and front passenger

Engine

• Type: Water-cooled flat-six engine; aluminium engine block and cylinder heads; four overhead camshafts, four valves per cylinder, variable inlet valve timing and lift (VarioCam Plus); hydraulic valve lifter; direct petrol injection; one three-way catalytic converter per cylinder bank, each with two oxygen sensors; engine oil 10.1 litres; electronic ignition with solid-state ignition distribution (six active ignition modules); thermal management for coolant circulation; auto start/stop function
• Bore: 97 mm
• Stroke: 77.5 mm
• Displacement: 3,436 cm³
• Compression ratio: 12.5:1
• Engine power: 250 kW (340 hp) at 7,400 rpm
• Maximum torque: 380 Nm at 4,750-5,800 rpm
• Power output per litre: 99.0 hp/l (72.8 kW/l)
• Maximum engine speed: 7,800 rpm
• Fuel type: Super Plus
• Electrical system: 12 Volt; alternator 2,100 W; battery 70 Ah, 450 A; electrical system recuperation

Power transmission

• Type: Engine and transmission bolted together to form a single drive unit; rear wheel drive; six-speed manual transmission; optional seven-speed Doppelkupplung (PDK)
• Clutch diameter: 240 mm (manual)

Chassis

• Front axle: Strut suspension (MacPherson type, Porsche optimised) with wheel-guiding strut and wheels independently mounted on transverse and longitudinal control arms; twin-tube gas-pressure dampers; electro-mechanical power steering
• Rear axle: Wheels independently guided on transverse control arms with longitudinal control arms, tie rods and suspension struts (McPherson type, optimised to Porsche requirements); cylindrical coil springs with internal dampers; anti-roll bar
• Porsche Active Suspension Management (PASM) with electronically controlled dampers; two manually selectable damping programmes.

Brakes

• Type: Dual-circuit brake system with separate circuits for front and rear axles; Porsche Stability Management (PSM); vacuum brake booster; brake assistant; electric duo-servo parking brake; autohold function
• Front axle: Four-piston alum. monobloc brake callipers, perforated and internally ventilated brake discs with 330 mm diameter and 28 mm thickness
• Rear axle: four-piston alum. monobloc brake callipers, perforated and internally ventilated brake discs with 299 mm diameter / 20 mm thickness

Wheels and Tyres

• Front wheels: 8 J x 20
• Front tyres: 235/35 ZR 20
• Rear wheels: 9.5 J x 20
• Rear tyres: 265/35 ZR 20

Dimensions

• Length 4,404 mm
• Width: 1,801 mm (with door mirrors 1,978 mm)
• Height: 1,284 mm
• Wheelbase: 2,475 mm
• Track width front: 1,526 mm
• Track width rear: 1,540 mm
• Luggage compartment capacity: front 150 l, rear 184 l
• Kerb weight (DIN): 1,345 kg (1,375 kg with the PDK)
• Permissible gross weight: 1,665 kg (1,695 kg with the PDK)

Performance (Manual)

• Top speed: 285 km/h (177 mph)
• 0-100 km/h: 4.9 seconds
• 0-200 km/h: 16.9 seconds
• 0-60 mph: 4.6 seconds
• 1/4 mile: 12,9 seconds

Performance (PDK)

• Top speed: 283 km/h (176 mph)
• 0-100 km/h 4.8 seconds (with Sport Plus 4.6 s)
• 0-200 km/h: 16.8 seconds (with Sport Plus 16.6 s)
• 0-60 mph: 4.5 seconds (with Sport Plus 4.3 s)
• 1/4 mile: 12,8 seconds (with Sport Plus 12.6 s)

Fuel Consumption and Emissions (Manual)

• Fuel consumption combined: 9.0 l/100 km
• Fuel consumption urban: 12.7 l/100 km
• Fuel consumption extra-urban: 7.1 l/100 km
• CO2 emissions combined: 211 g/km
• Emissions class: Euro 6
• Fuel tank capacity: 64 l
• Drag coefficient (cd): 0.31

Fuel Consumption and Emissions (PDK)

• Fuel consumption combined: 8.2 l/100 km
• Fuel consumption urban: 11.4 l/100 km
• Fuel consumption extra-urban: 6.3 l/100 km
• CO2 emissions combined: 190 g/km
• Emissions class: Euro 6
• Fuel tank capacity: 64 l
• Drag coefficient (cd): 0.31
